Leaky homes and leaky building syndrome

It’s past the 10 year cut-off - what are your options?

Traditionally, New Zealand homes have not been built fully weathertight. Even so, homes built before the 1990s were usually able to experience a small degree of leakage without suffering significant loss of durability. A number of factors made even the smallest amount of leakage risky in new residential construction. These included the introduction of untreated timber framing in the mid 1990s and the inappropriate use of new cladding systems on ‘Mediterranean’ or other complex architectural design styles from the late 1980s. Poor workmanship, inadequate design and lax council inspections also contributed. In short, bad designs, inappropriate materials and shoddy construction created a large number of homes that look sound but are at risk of leaking and major degradation.

Check with your lawyer first:

  • The CCC, or code compliance certificate, may have been issued some years after your building was completed, meaning Council could still be liable.
  • There could be warranty provisions in the sale and purchase agreement that give you legal recourse.
  • The vendor, or their agent, may have misrepresented the condition of the property to you

If and once you’ve checked the legal recourse, or decided not to bother then:

  • You’ll still need a report on the actual condition of your property.
  • From this you can make informed decisions on whether to do nothing, sell as-is, reclad, or to demolish & rebuild – either now or in the future.
  • Recladding is still cost-effective, but before you start, you need to have undertaken enough investigation to be satisfied the project won’t balloon beyond your budget once underway.
  • Cutting costs or being impatient at the beginning tends to lead to poor outcomes.
  • However, all building projects carry risk – the more unknowns the greater the risk. So for the faint-hearted and those on restricted budgets, it may be better to sell as-is.

Risk house

Leaky Home Diagram - Risk

1. Sloping head flashing

Risk House - Sloping Head Flashing Defect

Defect

Risk House - Sloping Head Flashing Resulting Damage

Resulting damage

2. Roof parapet

Risk House - Roof Parapet Defect

Defect

Risk House - Roof Parapet Resulting Damage

Resulting damage

3. Roof rainhead

Risk House - Roof Rainhead Defect

Defect

Risk House - Roof Rainhead Resulting Damage

Resulting damage

4. Deck outlet

Risk House - Deck Outlet Defect

Defect

Risk House - Deck Outlet Resulting Damage

Resulting damage

5. Cladding touching flashing

Risk House - Cladding Touching Flashing Defect

Defect

Risk House - Cladding Touching Flashing Resulting Damage

Resulting damage

6. Parapet capping

Risk House - Parapet Capping Defect

Defect

Risk House - Parapet Capping Resulting Damage

Resulting damage

7. Roof penetration

Risk House - Roof Penetration Defect

Defect

Risk House - Roof Penetration Resulting Damage

Resulting damage

8. Deck handrail fixings

Risk House - Deck Handrail Fixings Defect

Defect

Risk House - Deck Handrail Fixings Resulting Damage

Resulting damage

9. Door head flashing

Risk House - Door Head Flashing Defect

Defect

Risk House - Door Head Flashing Resulting Damage

Resulting damage

10. Pergola fixings

Risk House - Pergola Fixings Defect

Defect

Risk House - Pergola Fixings Resulting Damage

Resulting damage

11. Fascia plastered in

Risk House - Fascia Plastered In Defect

Defect

Risk House - Fascia Plastered In Resulting Damage

Resulting damage

12. Curved head flashing

Risk House - Curved Head Flashing Defect

Defect

Risk House - Curved Head Flashing Resulting Damage

Resulting damage

13. Handrail penetration

Risk House - Handrail Penetration Defect

Defect

Risk House - Handrail Penetration Resulting Damage

Resulting damage

14. Flat top balustrade

Risk House - Flat Top Balustrade Defect

Defect

Risk House - Flat Top Balustrade Resulting Damage

Resulting damage

15. Wall to deck clearance

Risk House - Wall to Deck Clearance Defect

Defect

Risk House - Walk to Deck Clearance Resulting Damage

Resulting damage

16. Wall to deck junction

Risk House - Wall to Deck Junction Defect

Defect

Risk House - Wall to Deck Junction Resulting Damage

Resulting damage

17. Balustrade to wall junction

Risk House - Balustrade to Wall Junction Defect

Defect

Risk House - Balustrade to Wall Junction Defect Resulting Damage

Resulting damage

18. Post penetration

Risk House - Post Penetration Defect

Defect

Risk House - Post Penetration Resulting Damage

Resulting damage

19. Downpipe onto roof

Risk House - Downpipe Onto Roof

Defect

Risk House - Downpipe Onto Roof Resulting Damage

Resulting damage

20. Apron flashing

Risk House - Apron Flashing Defect

Defect

Risk House - Apron Flashing Resulting Damage

Resulting damage

21. Garage door head flashing

Risk House - Garage Door Head Flashing Defect

Defect

Risk House - Garage Door Head Flashing Resulting Damage

Resulting damage

22. Cladding and framing close to ground

Risk House - Cladding and Framing Close to a Defect

Defect

Risk House - Cladding and Framing Close to a Resulting Damage

Resulting damage

23. Cladding close to paving at garage door

Risk House - Cladding Close to Paving at Garage Door Defect

Defect

Risk House - Cladding Close to Paving at Garage Door Resulting Damage

Resulting damage

24. Meter box

Risk House - Meter Box Defect

Defect

Risk House - Meter Box Resulting Damage

Resulting damage

25. Window head flashing

Risk House - Window Head Flashing Defect

Defect

Risk House - Window Head Flashing Resulting Damage

Resulting damage

26. Sill

Risk House - Sill Defect

Defect

Risk House - Sill Resulting Damage

Resulting damage

27. Horizontal control joint

Risk House - Horizontal Control Joint Defect

Defect

Risk House - Horizontal Control Joint Resulting Damage

Resulting damage

28. Louvre vent

Defect

Risk House - Louvre Vent Resulting Damage

Resulting damage

The remediation process:

What is involved?

The full remediation of a leaky building is effectively a three-stage process covering investigation and reporting, design, and administration of the construction contract. Prendos design and building surveying professionals provide comprehensive and efficient solutions to leaky homes, from initial diagnosis through to project completion, and including expert evidence for legal claims if required.

Investigation and reporting

The diagnosis of a leaky building is usually determined by a two stage investigation: an Initial Investigation and a follow-up Detailed Investigation.

An Initial Investigation is a non-invasive investigative procedure that involves a building surveyor meeting the homeowner on-site, to carry out a visual inspection of a building, discuss the history and homeowner’s concerns regarding the building, and to determine how a detailed investigation is best carried out.

Typically, as the result of an Initial Investigation, the building surveyor will produce a short report. However, if the homeowner is already aware of significant problems it may be more cost effective to proceed directly to a Detailed Investigation. A short initial visit may still be necessary to determine safe ways to gain access to the exterior.

A Detailed Investigation helps determine the extent of defects and other issues that may be affecting a building. The investigation typically involves destructive tests where small holes are drilled in the external building envelope to detect the presence of moisture behind the cladding. If elevated levels of moisture are detected, or there are other concerns, small areas (300mm x 300mm) of cladding may be removed, for example, and samples taken for analysis of decay and timber treatment.

Following the investigation a report is provided with a recommended course of action. The report is typically used as the basis for the remediation design. If it is being used to support legal action then the report will need to be more comprehensive.

Design

The building surveyor works closely with the client and our architect to develop a design brief that incorporates the necessary technical solutions to weathertightness issues, as well as taking into account building aesthetics and any additional work that may need to be undertaken. Once a brief is agreed concept plans are drafted and the building surveyor generates a scope of works. A quantity surveyor then prepares costings to assist the decision making process.

If a valuation is required to assist with obtaining bank funding, our property valuers can provide an anticipated market value based on the design concept.

On approval of the concept plans full working drawings are prepared. If the client is using the FAP scheme a FAP Repair and Payment Plan can also be prepared. Completed documents are submitted to the Council for building consent and tender documents are generated and supplied to interested building contractors.

Contact administration

On receipt of tenders from building contractors, a quantity surveyor undertakes a tender analysis and recommendations are presented to the client for acceptance. Construction contracts between the client and the builder are prepared with the building surveyor typically named as the Engineer to the Contract.

The building surveyor typically administers the remediation project. Site visits are undertaken regularly to observe the works and to deal with any unforeseen construction issues that may arise. The building surveyor also identifies any in-situ decayed framing needing replacement and collects any additional evidence of building failure for possible legal action. Regular site meetings are held with the client and builder. The building surveyor processes progress claims from the builder (typically monthly) to certify they are correct and – if the client is using the FAP scheme – assists with the compiling of milestone payments.

Final claims from the builder are processed and payment retentions are managed. A ‘Defects Liability Period’ commences at the practical completion of the project, whereby a portion of the builders payments are retained for a period to cover any minor works (such as paint touch ups) that may become apparent. Producer statements and trade guarantees are provided to the Council and client.

Legal Recourse

Many owners seek legal redress through either litigation or the Weathertight Homes Resolution Service (WHRS) from parties deemed to have contributed to their loss. Certain laws limit time periods for parties to be held accountable; it is critical that clients seek legal advice as early as possible to determine if limitation periods curtail any redress.
